FD-F Dispenser robot

Description:
Details:Features*The popular robot in FD series robots*Dispensing Area 200 X 200 X 50 ,300 X 300 X 100 and 400x400x100 mm*Dot, Lines, Arc etc. and 3D dispensing path is available.*100 programs, 4000 points per program*A hand-held Teach Pendant is provided for simple and intuitive

Product details description

Details:
Features
*The popular robot in FD series robots
*Dispensing Area 200 X 200 X 50 ,300 X 300 X 100 and 400x400x100 mm
*Dot, Lines, Arc etc. and 3D dispensing path is available.
*100 programs, 4000 points per program
*A hand-held Teach Pendant is provided for simple and intuitive programming functions
*SRE software is available for CAD file input (optional)
*Apply adhesives, cyanoacrylates, silicone, RTV, anaerobic resin, epoxy, UV cure formulations and many more fluids.
*Every robot will be with one small dispenser controller TS9150,tips barrels etc as full unit
